QS213 SIGHTS AND SCOPES



The QCNV QS213 Thermal Sight features a high-performance 256×192 resolution infrared imaging module, delivering detailed, lag-free thermal images for accurate target identification in darkness, fog, or complex outdoor environments. Designed with a compact and lightweight build, the QS213 ensures comfortable handling and fast aiming during hunting and tactical missions.

Equipped with a 13 mm lens and a 1.6-inch display, the device provides a sharp and intuitive viewing experience, enabling users to quickly lock onto heat signatures and track movement with confidence. Its small form factor and ergonomic structure make it ideal for hunters seeking portability without sacrificing clarity.

Whether used for night tracking, wildlife observation, or field navigation, the QS213 offers reliable performance, clear thermal imaging, and effortless operation anytime visibility is compromised.

Certified:

Product Assembly Demonstration

QS213
Key Parameters
Parameter Value
Objective Lens Size 13 F0.93
Field of View Angle (H × V) 13.5° × 10.1°
Display Parameters 1.6 inches · 360 × 320
Detector Resolution 256 × 192
Battery CR2
Maximum Working Hours 4 hours
External Power Interface Type-C, 5V
Material Aluminum alloy
IP Rating IP67
Operating Temperature -20°C ~ +50°C
Image Polarity White hot, black hot, red hot, fusion, and other types
Weight 110 g
Size L50 × W39 × H42 (mm)
