QVS 18 NIGHT VISION GOGGLES
The PVS18 Panoramic Night Vision Goggles are engineered to deliver an exceptionally wide field of view, giving users a broader and more detailed picture of their surroundings in low-light and no-light conditions. With its multi-lens panoramic design, the PVS18 significantly enhances spatial perception, helping operators identify threats, navigate terrain, and respond faster during night operations.
Built with an ergonomic structure and easy-to-operate controls, the PVS18 ensures stable performance even during long hours of use. The adjustable interpupillary mechanism allows users to tailor the viewing experience for optimal comfort, while the universal interface provides compatibility with a variety of helmets and mounts.
Whether for night observation, vehicle operation, equipment handling, or night-shift missions, the PVS18 boosts situational awareness and operational efficiency—making it a reliable choice for professional tactical teams and outdoor users.
Compatibility: IIT Q4/Q5
Certified:
Product Assembly Demonstration
| Indicator Name | Indicator Parameter |
|---|---|
| Recognition distance | Recognition range for standing and moving people ≥120 m with no moon |
| Image intensifier | GEN2+ / GEN3 |
| FOV angle | Horizontal ≥100°; Vertical ≥40° |
| Magnification | 1× |
| Eye relief | 35 mm |
| IPD adjustment range | 52 mm~72 mm |
| Continuous working time | ≥24 h (normal temperature) |
| IP rating | IP67 |
| Size | 215 mm × 73 mm × 113 mm |
| Weight | ≤775 g (without battery box) |
| Working temperature | -40°C ~ +55°C |
| Storage temperature | -50°C ~ +70°C |
