ELF C PRO CLIP-ON THERMAL IMAGER
The ELF-C PRO Clip-On Thermal Imager integrates advanced low-light enhancement with high-resolution thermal imaging (640×512), delivering exceptional situational awareness in environments where traditional night vision is limited. Engineered for detecting hidden objects, heat signatures, and camouflaged targets, the ELF-C PRO elevates field performance with precision and clarity.
Weighing only 65 grams, it is one of the lightest clip-on thermal devices in the world, offering effortless portability and rapid attachment to existing night-vision systems. The device supports Bluetooth remote control for fast and efficient operation, while integrated smart sensors enable various automatic adjustments to optimize imaging in real time. Auxiliary lighting further enhances visibility in challenging conditions.
Designed for professionals requiring compact power, the ELF-C PRO is ideal for tactical missions, law-enforcement operations, perimeter monitoring, and outdoor reconnaissance, enabling multi-mode fusion capabilities without adding unnecessary weight.
Certified:
Product Assembly Demonstration
| Parameter | Value |
|---|---|
| Detector | 640×512 · 12 μm |
| Aperture | F/1.0 |
| Magnification | 1× |
| FOV (H×V) | 35° × 30° |
| Recognition Distance | 275 m (Target size: 1.7 × 0.5, P(n)=99%) |
| Image Modes | Highlight / Outline (Adjustable threshold) |
| Automatic Control | ABC, Automatic Shutdown, Auto Standby |
| Bluetooth Remote Control | 25 mm |
| Exit Pupil Diameter | 2.4G |
| Compass | Electronic Compass (degree) |
| Power Supply | 1× CR123A Battery (Optional Battery Pack) |
| Battery Life (22°C) | 3 h (1× CR123A), 10 h (Battery Pack) |
| Compatible | PVS-14 (RNVG, DTNVS, 143D), L3Harris BNVD (PVS-3LA, GPNVG) |
| Weight | 80 g (with Battery), 65 g (without Battery) |
| Dimension | 86 mm (L) × 65 mm (W) × 40 mm (H) |
| Dimensions | 100 mm × 105 mm × 90 mm |
| Waterproof | 1.5 m for 0.5 h |
