ELF C CLIP-ON THERMAL IMAGER
The ELF-C Clip-On Thermal Imager is an ultra-lightweight thermal enhancement attachment designed to significantly improve night-vision performance under extreme darkness and minimal illumination. By clipping directly onto existing night-vision devices, the ELF-C enables instant fusion capability, allowing users to seamlessly switch between multiple viewing modes for superior target detection.
Engineered for rugged field use, the ELF-C features multi-mode thermal display, auxiliary lighting support, and multi-source power compatibility, ensuring stable operation across diverse mission environments. Its plug-and-play design allows for rapid installation without modifying the primary optical system, making it ideal for tactical teams, law-enforcement units, and professional outdoor operators who require flexible enhancement on demand.
Whether detecting hidden heat signatures, navigating complex structures, or reinforcing low-light imaging, the ELF-C provides a powerful and portable upgrade to any night-vision setup.
Certified:
Product Assembly Demonstration
| Parameter | Value |
|---|---|
| Magnification | 1× |
| Resolution | 640×512 pixels |
| Pixel Pitch | 12 μm |
| NETD | 25 mK |
| Frame Rate | 50 Hz |
| Lens System | 11.5 F1.0 |
| FOV | 30° |
| Mode | Outline, High-lights |
| Immersion | IP67 |
| Battery Type | CR123A ×1 / 18650 ×1 |
| Battery Life | 6 h (18650) |
| Dimensions | 85 × 65 × 43 mm |
| Weight | 95 g (without battery) |
